ENERGY SERIES WITH INTELLICORE®

Commercial Steel Overhead Doors

Clopay’s Intellicore overhead doors meet the needs of commercial buildings that require exceptional climate control. They feature polyurethane insulation which helps keep the building’s interior cooler in summer and warmer in winter.

Our energy-efficient commercial doors include stucco or woodgrain embossed steel exteriors with flush, minor ribbed, or raised panel section designs. Ideal applications include warehouses, manufacturing plants, municipal buildings and retail stores.

Models
ModelThicknessEmbossExterior SteelPatternIntellicore LogoR-Value*Std Max Width**Std Max Height
37303"Stucco27 GaugeMinor Ribbed
Intellicore Icon
27.230'2"20'0"
37242"Stucco24 GaugeMinor Ribbed
18.436'2"20'0"
37232"Woodgrain27 GaugeRaised Panel18.424'2"18'0"
37222"Stucco20 GaugeFlush
18.432'2"20'0"
37212"Woodgrain27 GaugeFlush18.424'2"18'0"
37202"Stucco27 GaugeMinor Ribbed
18.440'2"20'0"
37171 3/4" Stucco27 GaugeMinor Ribbed
16.224'2"20'0"
37181 3/4"Stucco27 GaugeFlush
16.224'2"20'0"
37151 3/8"Stucco27 GaugeMinor Ribbed
Intellicore Icon
12.918'2"16'0"

*Calculated door section R-value is in accordance with DASMA TDS-163
**For sizes over 32'2" wide consult factory for specific configuration requirements.






Options

Glass/Window Options:

Window Option 24
24" x 8"
(3715, 3717, 3718, 3720, 3724, 3730)
Window Option 24
24" x 12"
(3715, 3717, 3718, 3720, 3724, 3730)
904-Gray
FULL-VIEW*
(3715, 3717, 3718, 3720, 3722, 3724)
Window Option 19.5
19-1/2" x 12"
(3721, 3723)



*Intellicore® polyurethane option available in models 3720, 3722, & 3724


Glazing Material Options:

CLEAR GLASS
GRAY TINTED GLASS
BRONZE TINTED GLASS
MIRRORED GLASS*
OBSCURE GLASS
WHITE LAMINATE GLASS*
FROSTED GLASS OR ACRYLIC
CLEAR ACRYLIC
GRAY ACRYLIC
WHITE ACRYLIC
CLEAR POLYCARBONATE
BRONZE POLYCARBONATE
ALUMINUM PANEL COLOR MATCH

*Mirrored and laminate not available in 1/2"

Glass thickness available in 1/8", 1/4" and 1/2". Tri-wall polycarbonate thickness available in 1/2". Low-E available on insulated glass.





COLOR OPTIONS:

STANDARD WHITE
STANDARD WHITE
Almond
ALMOND
Desert-Tan
DESERT TAN
Sandtone
SANDTONE
Bronze
BRONZE
Chocolate  Brown
CHOCOLATE
GRAY
GRAY
Charcoal
CHARCOAL
CHOCOLATE
MOCHA
BLACK
BLACK
TRINAR® WHITE
TRINAR® WHITE
Additional Color Options

Premium finishing options include:

  • Custom Colors with Color Blast ® Garage Door Paint System
  • Bronze, dark bronze, black or custom color anodized finishing available on full-view sections only.

Clopay Color Blast® Logo

Performance Options Available:

Double-end hinge
3” Track
High performance hardware features 10 gauge end hinges, heavy-duty top bracket and 3" sealed roller with 5/8" stem.
Designed to counterbalance even the largest doors, commercial torsion spring assemblies can be designed for industry standard 10,000 cycles or can be upgraded to 25,000, 50,000 or 100,000 expected life cycles. Click here for details.
windcode-W
WindCode® reinforcement available up to W8 design pressure (DP) 52 PSF, depending on door configuration. Doors tested 50% greater than DP.
Clopay Extended 8-Year Hardware Warranty
Upgrade your standard door with industrial-grade components.

Specialty Options Available:

Mullions

carry-away
Carry-away, roll-away or swing-up mullions are available on select sizes.

Break-Away Section

break-away
Single section and double sections available on select sizes.

Pass Door

Charcoal Pass Door
32" wide x 80" high, max 16'2" wide section. Available in 2" thick doors only.

Safe-T-Stop™ Chain Hoist

Safe-T-Stop™ Chain Hoist
The Safe-T-Stop is a controlled descent sectional door hand hoist with an integral braking system allowing users to operate the door with confidence.
Features & Benefits

MODEL 3730

features 3730
Panel Design:

3" thick stucco embossed ribbed steel exterior

Steel Gauge: 27 gauge (.016" min) exterior; 28 gauge (.016" min) interior
Joint Design: Tongue & groove section with continuous foam thermal break prevents cold or heat from passing through the section
Thermal Conductivity: R-value 27.2* for maximum energy efficiency
Paint System: 3-stage paint process delivers maintenance free finish that resists rust prevention
Colors: Snow mist white, commercial brown, ColorblastTM
Limited Warranty: 10-year paint / 10-year delamination / one-year material & workmanship

MODEL 3720 / 3724 / 3722

features 3720, 3724, 3722
Panel Design:

(3720 & 3724) 2" thick stucco embossed steel exterior with minor ribbed pattern

(3722) 2" thick stucco embossed flush steel exterior

Steel Gauge: (3720) 27 gauge (.016" min) exterior; 28 gauge (.016" min) interior
(3724) 24 gauge (.022" min) exterior; 28 gauge (.016" min) interior
(3722) 20 gauge (.034" min) exterior; 28 gauge (.016" min) interior
Joint Design: Tongue & groove section with continuous foam thermal break prevents cold or heat from passing through the section
Thermal Conductivity: R-value 18.4* for maximum energy efficiency
Paint System: 3-stage paint process delivers maintenance free finish that resists rust perforation
Colors: (3720) Standard white, glacier white, commercial tan, chocolate, mocha brown, gray, Trinar white, Trinar beige, charcoal and Colorblast
(3724) Standard white, commercial tan, chocolate, black, gray, Trinar white and Colorblast
(3722) Standard white, chocolate and Colorblast
Limited Warranty: 10-year paint / 10-year delamination / one-year material & workmanship

MODEL 3717 / 3718

features 3717 and 3718
Panel Design:

(3717) 1 3/4" thick stucco embossed steel exterior with minor ribbed pattern

(3718) 1 3/4" thick stucco embossed flush steel exterior

Steel Gauge: 27 gauge (.016" min) exterior; 28 gauge (.016" min) interior
Joint Design: Tongue & groove section with continuous foam thermal break prevents cold or heat from passing through the section
Thermal Conductivity: R-value 16.2* for maximum energy efficiency
Paint System: 3-stage paint process delivers maintenance free finish that resists rust perforation
Colors: Pre-painted snow mist white, commercial brown, tan or gray. Optional Trinar white.
Limited Warranty: 10-year paint / 10-year delamination / one-year material & workmanship

MODEL 3715

features 3715
Panel Design: 1 3/8" thick stucco embossed steel with minor ribbing
Steel Gauge: 27 gauge (.016" min) exterior; 28 gauge (.016" min) interior
Joint Design: Tongue & groove section with continuous foam thermal break prevents cold or heat from passing through the section
Thermal Conductivity: R-value 12.9* for maximum energy efficiency
Paint System: 3-stage paint process delivers maintenance free finish that resists rust perforation
Colors: Pre-painted snow mist white or commercial brown, tan and gray
Limited Warranty: 10-year paint / 10-year delamination / one-year material & workmanship

*Calculated door section R-value is in accordance with DASMA TDS-163.

Specs/Drawings
Models BIM Shop Drawing Specification Literature(PDF) Instruction Manual(PDF) Warranty
Three Layer - Polyurethane - 1-1/2 inch
Model 3715 Ribbed, 27 Gauge RFA Icon DWG IconDXF IconPDF Icon DOC IconPDF IconRTF Icon 3715 Brochure Installation Manual PDF Icon
Three Layer - Polyurethane - 1-3/4 inch
Model 3717 Ribbed, 27 Gauge RFA Icon DXF IconDWG IconPDF Icon DOC IconPDF IconRTF Icon 3717, 3718 Brochure Installation Manual PDF Icon
Model 3718 Flush, 27 Gauge RFA Icon DXF IconDWG IconPDF Icon DOC IconPDF IconRTF Icon 3717, 3718 Brochure Installation Manual PDF Icon
Three Layer - Polyurethane - 2 inch
Model 3720 Ribbed, 27 Gauge RFA Icon DXF IconDWG IconPDF Icon DOC IconPDF IconRTF Icon 3720, 3721, 3723 Brochure Installation Manual PDF Icon
Model 3722 Flush, 20 Gauge RFA Icon DXF IconDWG IconPDF Icon DOC IconRTF IconPDF Icon 3722 Brochure Installation Manual PDF Icon
Model 3724 Ribbed, 24 Gauge RFA Icon DXF IconDWG IconPDF Icon PDF IconRTF IconDOC Icon 3724 Brochure Installation Manual PDF Icon
Three Layer - Polyurethane - 3 inch
Model 3730 Ribbed, 27 Gauge RFA Icon PDF IconDWG IconDXF Icon PDF IconRTF IconDOC Icon 3730 Brochure Installation Manual PDF Icon
Brochures Springs & Hardware

COMMERCIAL HARDWARE

Commercial doors are designed with hardware to meet demanding applications of commercial building usage. All commercial doors are provided with the following hardware as standard. For additional upgraded hardware see “Options” tab.

  • 14 gauge hinges
  • Commercial 10 ball steel rollers with options for nylon tire rollers
  • 10,000 cycle torsion springs
  • Steel step plate and lift handle for easy operation
  • Inside slide lock for increase security
  • 19 gauge steel hinge support plates
  • 18-gauge single end stiles; 16-gauge double end stiles
  • Galvanized aircraft cables with 7:1 safety factory
  • 2” or 3” track in a variety of configurations to meet building design requirements

COMMERCIAL TRACK APPLICATIONS

In commercial settings, space utilization and space constraints are important factors in choosing the correct hardware configuration for your application. Clopay track offerings and options enable you to make the most efficient use of available space. Options include standard lift, low head room front or rear mount, follow the roof pitch, full vertical or combination of these options.  Learn more

COMMERCIAL TORSION SPRINGS

Designed to counterbalance even the largest doors, commercial torsion spring assemblies can be designed for Industry standard 10,000 cycles or can be upgraded to 25,000, 50,000 or 100,000 expected life cycles. Click here for details
